20-80A DC charging current, suitable for electric vehicles with smaller battery capacity.
Compared with AC charging, DC charging is faster and can replenish the vehicle in a shorter time.
Small size, easy to install
Compliant with GB/T standard, compatible with various electric vehicles using this standard.
Moderate charging speed, suitable for electric vehicles for short-distance driving in cities
Compared with high-power DC chargers, it has lower cost and is more economical
Product Specifications
Definition
Standard
GB/T 20234.3-2015
Charging mode
4
Connection mode
C
Current type
DC
Cable color
Black
Shell color
Black
Environmental Performance
Ambient temperature (working)
-30～50℃
Ambient temperature (storage)
-40～80℃
Highest altitude
2000M
Ingress protection
IP54
Mechanical Performance
Insertion / Withdrawal cycles
＞10000times
Insertion / Withdrawal force
＜140N
Withstanding Impact force
Charging interface can withstand 1 meter height drop and 2 tons of car rolling
Electrical Performance
Rated current
20A,32A,40A,48A,65A,80A
Rated voltage
250V
Power contact number
3(PE, DC+, DC-)
Signal contact number
4(S+ S-, CC1 CC2)
Signal pin current
2A
Insulation resistance
＞100MΩ
Product Advantages
Ergonomic Design
The handle of our charging guns is ergonomically designed, intuitive, and easy to hold and use.
Safe Charging
Our chargers are durable and have an IP54 rating. This high level of protection ensures reliable performance and longevity, even in challenging situations.
Durable Construction
The plug is constructed from high-quality materials, including thermoplastic and copper alloy pins. This robust design ensures that the plug can withstand up to 10,000 times cycles.
Protective Plug Cover
We offer customized solutions, including different cable lengths and specifications. Customize your charging setup to meet your specific needs and preferences perfectly.
